Specifications
TUV certificationm
Simple,quick,safe and effective filed assembly
High mechanical endurance
Low transition resistance
|
Rated current : 30A(2-4mm²) |
Degree of protection: IP2*/IP67 |
|
Retaed voltage: 1000V DC |
Flame class : UL94-V0 |
|
Test voltage: 6000V(50Hz,1min) |
Safety class: II |
|
Overvoltage category:CATIII |
Suitable class: OD4.5-7.0(2.5-4.0mm²) |
|
Contact resistance of plug connectosr: 0.5mΩ |
Insertion force/withdrawal force: ≤50N/≥50N |
|
Contact material: Copper,Tin Plated |
Connecting System: Crimp connection |
|
Insulation material : PPO |
Temperature range: -40~+90 degree |
